water cooling metal fiber laser cutting machine for 1 - 3mm metal cutting

Rincian Produk

Sertifikasi: CE / FDA

Ketentuan Pembayaran & Pengiriman:

Kuantitas Minimum Order: 1 SET

Harga: USD Dapat dinegosiasikan

Packaging Details: Fumigation-free plywood wooden box with iron binding belt

Waktu pengiriman: 15 - 30 Hari Kerja

Ketentuan Pembayaran: T / T, L / C, Western Union

Kemampuan Supply: 2000 Unit per tahun

Deskripsi Produk Terperinci

Jenis Laser:	Serat Laser	Area pemotongan:	1500 * 3000mm
Mode Pendinginan:	Pendingin air	Aplikasi:	Pemotongan logam
Tegangan kerja:	380V / 50Hz	Ketebalan pemotongan:	3-4 Mm (Carbon Steel)
Daya laser:	300W	Perangkat Lunak Kontrol:	Cypcut

Main Introduction

1. The fiber optic laser cutter adopts world famous Germany fiber laser technology and USA imported laser cutting head & dynamic focus system, and fiber optic laser cutter can cut and punch different kind of metal materials with high precision and high speed.
2. Since laser is transmitted by fiber, it’s free maintenance, and also doesn't need to adjust the laser optical path at all. The fiber optic laser cutter greatly reduces the machines' fault rate and prolongs the working life.
3. The fiber cutter has large cutting area from 1.5M to 3M, and the fiber cutter can also meet the demands of various kinds of metal processing.

Fiber laser cutting machine Features

Kekuatan Laser	300 Watt
Sumber Laser	World Famous Germany Fiber laser technology
Jenis Laser	Serat Laser
XYZ Working area	15003000150 (mm)
Panjang gelombang laser	1070-1080nm
Max. Cutting Thickness	300w (1-3mm Carbon Steel)
Max. Cutting Speed	0-20 Meters / Min (up to materials)
Minimum line width	≤0.1mm
Location precision	≤ ± 0,05mm
Max. moving speed	100m/min
Re-location precision	± 0,02mm
Supporting Format	PLT, DXF, BMP, AI
Power demand	380V / 50Hz
Cooling Way	Pendingin air
Worktable max. load	1000KGS
Transmission Method	Ball Screw Transmission
Table-driven system	Japanese Imported Panasonic Servo Motor & Driving System
Focus Method	Following and Automatic Adjust Focus
Control Method	Offline Movement Control
Kontrol perangkat lunak	Cypcut Professional Laser Cutting Software
Kelas	Kelas 4 Laser

Fiber laser cutting machine Features

1. Excellent beam quality: Smaller focus diameter and high work efficiency.
2. Fast cutting speed: Cutting speed of this fiber cutter is more than 20m/min
3. Stable running condition: adopting the top world imported fiber lasers which has very stable performance, and key parts of the fiber optic laser cutter can reach 100,000 hours' lifetime;
4. High efficiency for photoelectric conversion: compare with Co2 laser cutting machine, fiber optic laser cutter has 3 times photoelectric conversion efficiency as much as it.
5. Low cost & low maintenance: saving energy and protecting environment. Photoelectric conversion rate is up to 25-30%. Electric power consumption is only about 20%-30% of the traditional Co2 laser cutting machine. Fiber cable transmission doesn't need to reflect lens so as to save maintenance cost;
6. Easy operations: fiber line transmission leads to no adjustment of optical path;
7. Super flexible optical effects: the design is compact and is also easy to reach all manufacturing requirements.

Applied materials of 300w Fiber Laser Cutting Machine
Pemotong serat terutama digunakan untuk memotong baja karbon, baja ringan, stainless steel, baja silikon, paduan aluminium, paduan titanium, lembaran baja galvanis, papan pengawetan, plat seng aluminium, tembaga dan berbagai jenis bahan logam. Ini adalah pemotong laser cnc yang dapat digunakan untuk melakukan pemotongan presisi tinggi. Ini juga dapat disebut mesin pemotong serat, pemotong laser serat optik, pemotong laser untuk logam, pemotong serat, pemotongan baja karbon, pemotong laser cnc.

Applied Industry of 300w Fiber Laser Cutting Machine
Pemotong laser untuk logam ini diterapkan dalam pemrosesan lembaran logam, penerbangan, penerbangan luar angkasa, elektronik, peralatan listrik, bagian kereta bawah tanah, mobil, mesin, komponen presisi, kapal, peralatan metalurgi, lift, peralatan rumah tangga, hadiah dan kerajinan, pemrosesan alat, perhiasan, iklan, logam asing, pengolahan berbagai industri pengolahan manufaktur.
